Cantek JDT75 Automatic Dovetailer- 3 PH 2 HP
Cantek JDT75 Automatic Dovetailer- 3 PH 2 HP
$11,000 (USD)
orCall 239-770-4474
Description
Features 21500 RPM spindle rotation for an extremely fine finish on dovetail joints High RPM spindle allows for precision machining of plywood & solid drawer sides Independent adjustment of both the tenon & the mortise depth for precise fitting of dovetail joints Dust hood for milling cutter Safety rail in front of spindle motor High quality pneumatics for smooth feeding, resulting in quality cutting Cast iron base to ensure vibration free cutting Automatic lubrication system to spindle stroke 3 cycle speeds for best finish results Specs
Specifications
| Manufacturer | Cantek |
| Condition | New |
| Stock Number | 4275.101.4S (7.5HP, 5Ph) |
| WORK PIECE DIMENSIONS | |
| Working length | min: 7.87″ max: 59″ |
| Working width | min: 2.36″ max: 16.93″ |
| Vertical material thickness | 0.275″ to 2.36″ |
| Horizontal material thickness | 0.394″ to 1.18″ |
| Fixed pitch | 25mm |
| Spindle speed | 21,500 RPM |
| Cutter shank diameter | 0.472″ (12mm) |
| Spindle motor | 2HP |
| Feed motor | 2HP> |
| Feed speeds (3) | 16, 22, 31 cycles/min |
