OMGA- Radial 900/7 18'' Radial Arm Saw
OMGA- Radial 900/7 18'' Radial Arm Saw
$16,555 (USD)
orCall 239-770-4474
Description
18" Radial Arm Saw 7HP Motor 35 1/2" Cross Cut Capacity 43 5/16" Rip Capacity. Cast Iron Arm.
These precision radial arm saws are very versatile, multi-purpose machines. This versatility is due to the possibility of swiveling and tilting both in the horizontal and vertical axis which makes the machines especially suitable for furniture manufacturers, frame makers, sawmills and carpentry shops. There is a wide range of accessories available to adapt the machine to each and every requirement.
Available in 230 and 460 V.
DATA SHEET
ACCESSORIES
Specifications
| Manufacturer | OMGA |
| Condition | New |
| Max. Depth of cut 45 Deg. | 4 7/8" 4 3/16" |
| Motor power | 7 7 |
| Saw bore | 1" 1" |
| Saw Diameter | 20" 18" |
| Arbor speed RPM | 3400 3200 |
| Bevel positive stops | 0-45 0-45 |
| Cross cut capacity | 49 7/32" 35 1/2" |
| Table Size | 68"x44" 47"x39" |
| Max. dado capacity | 1 3/4" 1 1/2" |
| Max. Depth of cut -90 | 6 7/8" 5 7/8" |
| Miter positive stops | 45-0-45 45-0-45 |
| Overall dimensions | 80"x55" 59"x48" |
| Ripping capacity | 59" 43 5/16" |
| Shipping Weight Lbs. | 1078 800 |
| Crated Dimensions | 79"x19"x55" 63"x19"x43" |
| Dado Head Guard 12" x 2 3/8" | $350.00 |
| Pneumatic Hold-Down Clamp | $885.00 |
| Pneumatic Horizontal Clamp | $1,042.00 |
| Flip Over Stop | $107.00 |
| Pneumatic Flip over Stop | $747.00 |
| Roller Table 6' X 24" RH | $2,056.00 |
| Roller Table 6' X 24" LH | $2,056.00 |
| 3' Aluminum Fence Extension | $418.00 |
| 6' Aluminum Fence Extension | $592.00 |
| Automatic Feed of the Head (RADIAL 900) | $4,491.00 |
| 20" Blade Guard | $862.00 |
| Front Lifting Handle (RADIAL 900) | $995.00 |
